2022 NEW KRISTALL GW20 48V15AH 750W FAT TIRE FOLDING EBIKE INTERGRATED RIM MOTOR

$1,999.00 $1,799.00

Specifications Brand : KRISTALLMode : GW20 Overall sizeBike length: 172cmSeat height: 92-103cmHandlebar height: 122-127.5cmRear seat height: 65cm Size after folding : 95*75*48cmPackage Size : 97*81*48cmMax weight load of the rear rack : 120kgMax. Loading : 150kgNet weight : 27kgGross weight : 36KGBattery weight : 4KGTop speed : 30-45km/hRange Pure Electric:...

Battery capacity

Why Choose Us ?

Ebikeboys is an establish Sydney Retailer and offers professional Ebike Sales from popular brands.

Professional Advise

We are bikers ourselves so we understand very well. We will provide you courteous and friendly advice on any brand/type

After Sales Service

We provide free after sales support and service on all of our products. One Free Professional Assembly and Service available (T&Cs Apply)
2022 NEW KRISTALL GW20 48V15AH 750W FAT TIRE FOLDING EBIKE INTERGRATED RIM MOTOR

2022 NEW KRISTALL GW20 48V15AH 750W FAT TIRE FOLDING EBIKE INTERGRATED RIM MOTOR

Specifications

Brand : KRISTALL
Mode : GW20

Overall size
Bike length: 172cm
Seat height: 92-103cm
Handlebar height: 122-127.5cm
Rear seat height: 65cm

Size after folding : 95*75*48cm
Package Size : 97*81*48cm
Max weight load of the rear rack : 120kg
Max. Loading : 150kg
Net weight : 27kg
Gross weight : 36KG
Battery weight : 4KG
Top speed : 30-45km/h

Range
Pure Electric: 40-55km
Boost Mode: 80-110km

Grade Ability : 30 degree
Battery type : 18650 Lithium battery
Rated voltage (V) : 48V
Input voltage (V):54V
Battery capacity (AH) : 15Ah
Motor power : 750W
Input voltage (V) : 100-240V
Rated current : 2A
Tire : CST 20*4.0in
Frame material : Aluminium alloy 6061
Gear :7 Speeds Gear
Torque (Nm) : 80Nm
Charging socket :European Standard Round Head

Pattern
1. Electric-only mode
2. Cycling mode ( without electric )
3. Assistant mode

Brake : Disc brake

Package

1 x KRISTALL GW20 Electric Bike
1 x Charger ( AU Plug )
1 x Basket
1 x Back Rack
1 x Taillights
1 x Reapir Tools
1 x Protable Pump
1 x Manual
1 year warranty on electric parts.
